Hikvision
Villa door station
SKU: DS-KV6133-WME1-SURFACE · 視像對講機
查詢報價
Hikvision Villa door station DS-KV6133-WME1/Surface
※ 價／分類來自 ERPNext，內容／配件來自 master Mongo。
概覽
規格
System parameters
| Operation system | Linux |
| ROM | 32 MB |
| RAM | 256 MB |
| Processor | Embeded high performance processor |
Display parameters
| Screen size | / |
| Operation method | / |
| Type | / |
| Resolution | / |
Video parameters
| Lens | 1 |
| Resolution | Main stream: 1920 × 1080p，1280 × 720p Sub stream: 1280 × 720p，640 x 480p |
| FOV | Horizontal:129°,Vertical: 75° |
| Wide dynamic range (WDR) | Support 120 dB |
| Supplement light | IR light, up to 2.5 m |
| Video compression standard | H.264 |
Audio parameters
| Audio input | 1 built-in omnidirectional microphone |
| Audio compression standard | G.711 U、G.711 A、Opus、AAC-LD、AAC-LC、G.726、G.722.1 |
| Audio output | 1 built-in loudspeaker |
| Audio compression bitrate | 16/32/64 Kps |
| Audio quality | Noise suppression and echo cancellation |
| Volume adjustment | Adjustable |
Capacity
| User capacity | 2000 |
| Face capacity | / |
| Card capacity | 10000 |
Network parameters
| Network protocol | TCP/IP, RSTP |
| Wi-Fi | 2.4GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n |
| Bluetooth | / |
| 3G/4G | / |
Device interfaces
| Alarm input | 4 |
| Network interface | 1 RJ-45, 10/100 Mbps self-adaptive |
| TAMPER | 1 |
| Exit button | 1 |
| RS-485 | 1 |
| USB | / |
| Wiegand | / |
| TF card | 1(Reserved) |
| Alarm output | / |
| Lock control | 1 relay, Max. 30 VDC 2 A |
| Door contact input | 1 |
| Audio output | 1 external loudspeaker(Reversed) |
General
| Button | 1 physical button |
| Installation | Surface mounting |
| Indicator | 2 |
| Protective level | IP65 |
| Working temperature | -40 °C to 53 °C (-40 °F to 127.4 °F) |
| Working humidity | 10% to 95% (no-condensing) |
| Dimension (W × H × D) | 181.6 mm × 103.6 mm × 29.5 mm (7.1" × 4.0" × 1.1") |
| Battery | / |
| Application environment | Outdoor |
| Power consumption | ＜ 10 W |
| Language | English, Arabic, French (Europe), Russian, Spanish (Europe), Italian, German, Polish, Turkish, Portuguese, Portuguese (Brazil), Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese |
| Power supply | 12 VDC, 1.5 A,IEEE802.3af, Standard PoE |
